Near-IR and Dual Bandpass Filters On JNS Glass & Coatings

Near-IR Bandpass and Dual Bandpass Filters selectively allows the passage of visible light and a narrow band of IR light while blocking unwanted wavelengths. By reducing the amount of IR light captured, the optical filter improves the image quality, reduces noise, and enhances the accuracy of IR sensing systems.

Item #	Item Name	Useful Range	Tolerance (±)	Peak Transmission
BP695	N/A Near-IR Bandpass Filter	N/A 680 to 720 nm	N/A 10 nm	N/A ≥90 %
BP735	N/A Near-IR Bandpass Filter	N/A 715 to 780 nm	N/A 10 nm	N/A ≥90 %
DB735	N/A Dual Bandpass Visible + 735 nm	N/A 405 to 645 nm725 to 755 nm	N/A 20 nm	N/A ≥90 %
BN740	N/A Narrow Near-IR Bandpass Filter	N/A 730 to 755 nm	N/A 7 nm	N/A ≥85 %
Bi750	N/A Near-IR Interference Bandpass Filter	N/A 710 to 765 nm	N/A 5 nm	N/A ≥90 %
BN785	N/A Narrow Near-IR Bandpass Filter	N/A 800 to 1100 nm	N/A 10 nm	N/A ≥90 %
BP800	N/A Near-IR Bandpass Filter	N/A 770 to 790 nm	N/A 7 nm	N/A ≥85 %
Bi808	N/A Near-IR Interference Bandpass Filter	N/A 798 to 820 nm	N/A 5 nm	N/A ≥85 %
BN810	N/A Narrow Near-IR Bandpass Filter	N/A 798 to 820 nm	N/A 7 nm	N/A ≥85 %
Bi830	N/A Near-IR Interference Bandpass Filter	N/A 810 to 850 nm	N/A 5 nm	N/A ≥90 %
Bi832	N/A Near-IR Interference Bandpass Filter	N/A 822 to 846 nm	N/A 5 nm	N/A ≥90 %
BP850	N/A Near-IR Bandpass Filter	N/A 820 to 910 nm	N/A 10 nm	N/A ≥90 %
BN850	N/A Narrow Near-IR Bandpass Filter	N/A 840 to 865 nm	N/A 7 nm	N/A ≥85 %
DB850	N/A Dual Bandpass Visible + 850 nm	N/A 405 to 645 nm835 to 875 nm	N/A 10 nm for Near-IR 20 nm for Visible	N/A ≥90 %
DB475/850	N/A Dual Bandpass Blue + 850 nm Near-IR	N/A 460 to 490 nm830 to 870 nm	N/A 5 nm	N/A ≥90 %
DB550/850	N/A Dual Bandpass Blue + 850 nm Near-IR	N/A 535 to 565 nm830 to 870 nm	N/A 5 nm	N/A ≥85 %
DB660/850	N/A Dual Bandpass Red + 850 nm Near-IR	N/A 645 to 675 nm830 to 870 nm	N/A 5 nm	N/A ≥90 %
DB395/870	N/A Dual Bandpass Absorptive Visible + Near-IR	N/A 375 to 425 nm745 to 970 nm	N/A 10 nm	N/A ≥90 %
Bi850	N/A Near-IR Interference Bandpass Filter	N/A 845 to 860 nm	N/A 5 nm	N/A ≥88 %
BP880	N/A Near-IR Bandpass Filter	N/A 845 to 930 nm	N/A 10 nm	N/A ≥90 %
BN880	N/A Narrow Near-IR Bandpass Filter	N/A 855 to 890 nm	N/A 7 nm	N/A ≥85 %
Bi905	N/A Near-IR Interference Bandpass Filter	N/A 895 to 915 nm	N/A 5 nm	N/A ≥88 %
BN940	N/A Narrow Near-IR Bandpass Filter	N/A 928 to 955 nm	N/A 7 nm	N/A ≥90 %
Bi940	N/A Near-IR Interference Bandpass Filter	N/A 930 to 952 nm	N/A 5 nm	N/A ≥85 %
DB940	N/A Dual Bandpass Visible + 940 nm	N/A 405 to 650 nm925 to 965 nm	N/A 10 nm for Near-IR 20 nm for Visible	N/A ≥90 %

BP695

N/A Near-IR Bandpass Filter

N/A 680 to 720 nm

N/A 10 nm

N/A ≥90 %

BP735

N/A Near-IR Bandpass Filter

N/A 715 to 780 nm

N/A 10 nm

N/A ≥90 %

DB735

N/A Dual Bandpass Visible + 735 nm

N/A 405 to 645 nm725 to 755 nm

N/A 20 nm

N/A ≥90 %

BN740

N/A Narrow Near-IR Bandpass Filter

N/A 730 to 755 nm

N/A 7 nm

N/A ≥85 %

Bi750

N/A Near-IR Interference Bandpass Filter

N/A 710 to 765 nm

N/A 5 nm

N/A ≥90 %

BN785

N/A Narrow Near-IR Bandpass Filter

N/A 800 to 1100 nm

N/A 10 nm

N/A ≥90 %

BP800

N/A Near-IR Bandpass Filter

N/A 770 to 790 nm

N/A 7 nm

N/A ≥85 %

Bi808

N/A Near-IR Interference Bandpass Filter

N/A 798 to 820 nm

N/A 5 nm

N/A ≥85 %

BN810

N/A Narrow Near-IR Bandpass Filter

N/A 798 to 820 nm

N/A 7 nm

N/A ≥85 %

Bi830

N/A Near-IR Interference Bandpass Filter

N/A 810 to 850 nm

N/A 5 nm

N/A ≥90 %

Bi832

N/A Near-IR Interference Bandpass Filter

N/A 822 to 846 nm

N/A 5 nm

N/A ≥90 %

BP850

N/A Near-IR Bandpass Filter

N/A 820 to 910 nm

N/A 10 nm

N/A ≥90 %

BN850

N/A Narrow Near-IR Bandpass Filter

N/A 840 to 865 nm

N/A 7 nm

N/A ≥85 %

DB850

N/A Dual Bandpass Visible + 850 nm

N/A 405 to 645 nm835 to 875 nm

N/A 10 nm for Near-IR 20 nm for Visible

N/A ≥90 %

DB475/850

N/A Dual Bandpass Blue + 850 nm Near-IR

N/A 460 to 490 nm830 to 870 nm

N/A 5 nm

N/A ≥90 %

DB550/850

N/A Dual Bandpass Blue + 850 nm Near-IR

N/A 535 to 565 nm830 to 870 nm

N/A 5 nm

N/A ≥85 %

DB660/850

N/A Dual Bandpass Red + 850 nm Near-IR

N/A 645 to 675 nm830 to 870 nm

N/A 5 nm

N/A ≥90 %

DB395/870

N/A Dual Bandpass Absorptive Visible + Near-IR

N/A 375 to 425 nm745 to 970 nm

N/A 10 nm

N/A ≥90 %

Bi850

N/A Near-IR Interference Bandpass Filter

N/A 845 to 860 nm

N/A 5 nm

N/A ≥88 %

BP880

N/A Near-IR Bandpass Filter

N/A 845 to 930 nm

N/A 10 nm

N/A ≥90 %

BN880

N/A Narrow Near-IR Bandpass Filter

N/A 855 to 890 nm

N/A 7 nm

N/A ≥85 %

Bi905

N/A Near-IR Interference Bandpass Filter

N/A 895 to 915 nm

N/A 5 nm

N/A ≥88 %

BN940

N/A Narrow Near-IR Bandpass Filter

N/A 928 to 955 nm

N/A 7 nm

N/A ≥90 %

Bi940

N/A Near-IR Interference Bandpass Filter

N/A 930 to 952 nm

N/A 5 nm

N/A ≥85 %

DB940

N/A Dual Bandpass Visible + 940 nm

N/A 405 to 650 nm925 to 965 nm

N/A 10 nm for Near-IR 20 nm for Visible

N/A ≥90 %

Item #

Item Name

Useful Range

Tolerance (±)

Peak Transmission
